Optimus-50 BM is automatic boom barrier with the BMDrive® mechanism is a reliable and efficient solution for access control in private, commercial, and industrial zones. At the heart of equipment is the BMDrive® — a robust mechanism powered by a durable BLDC gear motor, ensuring long-term, trouble-free operation. With an adjustable opening and closing speed of 3 to 5 seconds, the barrier supports high vehicle throughput, making it ideal for busy access points. The body of the barrier is made from galvanized steel with a powder-coated finish, offering excellent corrosion resistance, while the lightweight aluminum boom is built to withstand strong wind loads.
Product specifications and complete sets may differ from that shown on the photo.
- Specifications
- Datasheet
- Technical documentation
- Gallery
| Model | RB 392-05 | |
| Cabinet dimensions (LхWхВ) | 255 х 340 х 1050 mm | |
| Arm length | 3 - 5 m | |
| Operation mode | Left / right version | |
| Raising/lowering speed, s | 3 - 5 sec | |
| Mechanism | BMDrive® servo-driven (BLDC) | |
| Weight | 45 kg | |
| Usage rate | 90 % | |
| Operation frequency | 300 cycles / hour | |
| MCBF | 3 000 000 cycles | |
| MTTR | < 25 min | |
| Temperature range | from -40 to + 60** | |
| Maximum power consumption | 240 W | |
| Power supply | 220-240 V, 50/60 Hz | |
| Indication | standard - RGB indication on all sides of the cabinet optional - arm ligh |
|
| Standart materials | Galvanized steel with powder coating | |
| Available housing | Brushed SS AISI 304 Brushed SS AISI 316 |
|
| Material of arm | Powder coated aluminium | |
| *other arm length is available up on request **For temperatures below -10 °C heating system to be used / for temperatures above +40°C cooling system to be used (option) |
||
